Subject: Dearborn Side Deliver Rake - 14-20/14-40-dealer parts book

[Back] [Return to Top of Forum]

Ed Gooding (VA)    Posted 09-30-2006 at 06:12:58 [URL]        [Reply] [Email]
  • Dearborn Side Deliver Rake - 14-20/14-40-dealer parts book
  • This is a May 1951 publication of a dealer parts book for the Dearborn models 19-20 (prior version) and 19-40 Heavy Duty Side Delivery Rake:

    Please review our tutorial in our How-To's section (see the red menu bar at the top of the screen) on how to best capture the following pages to your PC, instead of trying to print them with your browser.
    Note: this technique will work with any image on any web site.

    Enjoy................Ed

    Ed Gooding (VA)    Posted 09-30-2006 at 06:14:31 [URL]        [Reply] [Email]
  • Frame Assembly (3 pages)

  • Ed Gooding (VA)    Posted 09-30-2006 at 06:15:20 [URL]        [Reply] [Email]
  • Reel Height Control Assembly (2 pages)

  • Ed Gooding (VA)    Posted 09-30-2006 at 06:16:26 [URL]        [Reply] [Email]
  • Sprocket - universal drive (3 pages)

  • Ed Gooding (VA)    Posted 09-30-2006 at 06:17:22 [URL]        [Reply] [Email]
  • Reel Assembly (3 pages)

  • Dave Sandrock    Posted 06-04-2008 at 16:57:20 [URL] [DELETE]        [Reply] [Email]
  • Re: Reel Assembly (3 pages)
  • Where can I find teeth?

    Angel    Posted 08-04-2008 at 11:51:24 [URL] [DELETE]        [Reply] [Email]
  • did you find teeth
  • Hi,
    Noticed that you to are looking for teeth to a 14-20 dearborn hay rake, was you able to find them, if so where??? Not having any luck.
    Thanks

    David E. Sandrock    Posted 08-05-2008 at 01:13:02 [URL] [DELETE]        [Reply] [Email]
  • Re: did you find teeth
  • Try this link http://www.balsters.net/baler-rake-sideteeth.html

    Dave Sandrock V-Bench Hay Cattle    Posted 08-04-2008 at 12:09:14 [URL] [DELETE]        [Reply] [Email]
  • Re: did you find teeth
  • I finally bought two rakes for parts but all of the teeth are pretty worn. Any Ideas?

    Ed Gooding (VA)    Posted 09-30-2006 at 06:18:09 [URL]        [Reply] [Email]
  • Wheel & Axle Assembly (1 page)
